Details
Output
Output power capacity
865Watts / 1.5 kVA
Max Configurable Power (Watts)
865Watts / 1.5 kVA
Nominal Output Voltage
120V
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Topology
Line Interactive
Waveform type
Stepped approximation to a sinewave
Output Connections
(5) NEMA 5-15R (selector_surgetitle)
(5) NEMA 5-15R (Battery Backup)
Transfer Time
8ms typical : 12ms maximum
Input
Nominal Input Voltage
120V
Input frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
NEMA 5-15P
Cord Length
6ft (1.83meters)
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules
1
Typical recharge time
8hour(s)
Replacement Battery
Expected Battery Life (years)
3 - 5
RBC Quantity
1
Extended Run Options
Runtime
Efficiency
Communications & Management
Interface Port(s)
USB
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating
354Joules
Data Line Protection
Cable modem / Video protection, Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector)
Filtering
Full time multi-pole noise filtering :5% of IEEE surge let-through : zero clamping response time: instantaneous
Physical
Maximum Height
11.85inches (301mm, 30.1CM)
Maximum Width
4.41inches (112mm, 11.2CM)
Maximum Depth
15.04inches (382mm, 38.2CM)
Net Weight
26.62lbs. (12.1KG)
Shipping weight
29.37lbs. (13.35KG)
Shipping Height
15.24inches (387mm, 38.7CM)
Shipping Width
9.37inches (238mm, 23.8CM)
Shipping Depth
19.21inches (488mm, 48.8CM)
Master Carton Units
1.0
Units per Pallet
20.0
SCC Codes
1073130426877 9
Environmental
Operating Temperature
32 - 104 °F (0 - 40 °C)
Operating Relative Humidity
0 - 95 %
Operating Elevation
0-30000ft (0-9000meters)
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0-50000ft (0-15000meters)
Audible noise at 1 meter from surface of unit
45.0dBA
