Details
- provides source selection, automatic source acquisition and confi guration, advanced windowing features, seamless switching, video effects and integrated control for professional video presentations.
- the system can efficiently support from 1-32 screens with any combination of independent display or seamless wide-screen display elements.
- full flexibility
- supports six independent picture-in-picture (PiP) or key layers, or three transitioning PiP images.
- Ideally suited for large blended widescreen applications features 1:1 pixel sampling, motion adaptive de-interlacing for both standard and high definition sources, 3:2 and 2:2 pull down detection, low video delay, aspect ratio correction, real-time window manipulation.
- each system is designed to grow in tandem with your creative requirements. With a full array of unsurpassed features, dynamic input flexibility and the superb quality of Barco's scaling technology
- Athena proprietary high-performance scaling
- Low video delay - less than 3 input fields
- Z-order control (priority layers) for overlapping PIP or key images
- Each mixer layer is dynamically re-assignable as a mixing (transitioning) PIP, or as two individual (SPLIT) nontransitioning PIP or key images.
- Still frame : frame grab of background and downstream key sources
- Complete look-ahead preview
- On-screen display (preview monitor) of layer information and status
- Supports blended widescreen projection
- Output synchronization: free-run or vertically locked to NTSC/PAL blackburst
Additional Information
Resolution | Computer Resolutions VGA (640 x 480) through UXGA (1600 x 1200) · HDTV Resolutions up to 1920 x 1080 (720p,1080I, 1080p) · 2048 |
---|---|
Power | 120-240 VAC - 50/60 Hz., Autoselecting 1.0A maximum |
Analog Input | RGBHV/RGBS/RGsB computer video, YPbPr video (SD or HD), S-video, or Composite video on 15-pin HD connector |
