Details
The PDS series is designed to meet today's requirements for a high-quality, easy-to-use and fast seamless switcher with more digital inputs at an affordable price. Thanks to its straightforward setup and operation the PDS is a perfect fit for live events, boardrooms, hotel ballrooms, houses of worship, education and training facilities and fixed installations. EDID 1.3 specification supported The PDS-902 3G model features four DVI-I inputs with full HDCP 1.0 support, one 3G/HD/SD SDI and four universal analog inputs. All analog and DVI inputs support the EDID 1.3 specification. Users can capture and store up to three images that can be used as a LOGO source during the presentation. Built-in test patterns are also provided. Preview output The PDS-902 3G offers simultaneous program output via the DVI and analog connectors. It also include an SDI output supporting SD/HD/3G rates and BarcoLink for easy connection to your Barco projectors. In addition, the switcher offers a preview output that can be set at different resolution than the program output. Users have the option of displaying one of three signals on the preview output: program, preview or test pattern.
Description
- 1x 3G/HD/SD-SDI Input
- 4 x DVI-I Input
- 4x VGA Input
- HDCP Compliant
- Up to WUXGA 1920x1200 Compatible
- Program and Preview Output
- Up to Three Logo Stores/Recall
- Dual PIP mode
- Built-in Test Patterns
- 1 RU Height
Additional Information
| Control | 1 x Ethernet RJ-45, 10/100 Mbps auto-sense Computer, tablet, smartphone, or Encore or ScreenPRO-II controller via Ethernet link |
|---|---|
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Operating Humidity | 0 to 95% non-condensing |
| Power | Input power: 100-240 VAC 50/60Hz 2a max |
