Details
Axis Specifications
|
Frequency Response |
45–25kHz ±3dB |
|
Horizontal Dispersion |
80° |
|
Vertical Dispersion |
30° |
|
High Frequency Transducer |
1.25" x 2.4" (3.2cm x 6.1cm) Folded Motion XT Transducer with 4.5" x 2.75" (11.4cm x 7cm) diaphragm. |
|
Low Frequency Transducer |
Two 5.25" (13.4cm) aluminum cone with cast aluminum basket. Concave dust cap. |
|
Sensitivity |
94 dB/2.83 volts/meter |
|
Impedance |
4 Ohms Compatible with 4, 6, or 8 Ohm rated amplifiers. |
|
Recommended Amplifier Power |
20—250 watts per channel |
|
Crossover Frequency |
700 & 2,000 Hz |
|
Components |
Custom air core coil inductors. Polyester film capacitors in series and low DF electrolytic capacitors. Overall system thermal/current protection. |
|
Inputs |
Push style binding posts. |
|
Weight |
13 lbs. (5.9 kg) |
|
Dimensions (overall size) |
15.2" x 7.8" x 3.9 " |
