Details
Panasonic's projector features a redesigned air cooling system that achieves 30-dB quietness even when operating with full brightness. It expands usability in noise-critical situations. Panasonic's original Dynamic RGB Booster also ensures an excellent balance of brightness and color reproduction. The Dual-lamp system contributes to reliable operation, less downtime, and low maintenance cost.
Features
Virtually unnoticeable operation with 30 dB in normal mode
Thanks to a carefully designed airflow control system and cooling fans, operation noise is dramatically reduced to 30 dB even when the projector is used with the lamps at full power in normal mode, making the projector very quiet. The projector intakes air from the bottom of the unit and exhausts it from the back, eliminating openings in the front and sides to eliminate noise leakage.
The Dynamic RGB Booster enhances both
Brightness and color reproduction Panasonic's Dynamic RGB Booster achieves high image quality with levels of color reproduction and brightness that make each color stand out. It combines Panasonic's proprietary Vivid Color Control technology with a Lamp Modulation Drive System for a 1-chip DLP projector that produces bright and vivid colors. Images are analyzed frame by frame, and scene-linking and real-time modulations are used to achieve high brightness and vivid color reproduction.
Detail clarity processor brings depth and clarity to details
This advanced image-processing circuit analyzes the video signal frequency range for each scene by extracting data on the distribution of high, mid, and low-frequency components, and brings out fine details accordingly. The resulting images have a more natural, three-dimensional appearance with crisp, clear detail.
Dust-resistant optical block
The optical block, the heart of the projector, is hermetically sealed to resist the effects of dust and other particles in the air, which makes it possible to remove the air filters for optics. It also contributes to the low TCO.
Dual-lamp system prevents image interruptions
This system eliminates the interruption if a lamp should fail. The Lamp Relay mode also operates the lamps alternately to enable 24/7 projection.
Digital Link transmits digital signals up to 150 m with a single cable
Equipped with a Digital Link terminal, the projector allows transmission of HDMI, uncompressed HD digital video, and control signals (Ethernet, RS- 232C) for up to 150 m through a single Cat5e cable or higher. This simplifies cabling and system upgrades, making it ideal for ceiling-mounted and other permanent installations.
Geometric adjustment for specially shaped screens
This function adjusts the image for projection onto spherical, cylindrical and other specially shaped screens. You can make the adjustment easily using only the remote control, with no external equipment needed. 4-Corner Adjustment and Keep Aspect Off functions also simplify fine adjustment.
Multi-screen support system seamlessly connects multiple screens
The multi-screen support system optimally adjusts multiple screens: edge blending, color matching and digital image enlarging.
Additional Information
| Aspect Ratio | Native: 16:10 |
|---|---|
| Brightness (ANSI Lumens) | Normal Mode: 7000 Lumens |
| Contrast Ratio | 3000:1 |
| Resolution (Native / Max) | 1280 x 800 (WXGA) |
| Power Consumption | Normal Mode: 790 W, Standby Mode (Eco): 0.3 W, Standby Mode (Normal): 3 W |
| Projection Screen Size (Diagonal) | 50 - 600" / 127.00 - 1524.00 cm |
| Throw Ratio | 1.8 - 2.5:1 |
| Lens Shift | Vertical: + 60%, Vertical: to 16%, Horizontal: + 30%, Horizontal: to 10% |
| Operating Temperature | 32 to 113°F (0 to 45°C) |
| Remote Control | Yes |
| Operating Humidity | 10 - 80% |
| Brightness Uniformity | 90% |
| Keystone Correction | Yes, Vertical: ± 40°, Yes, Horizontal: ± 15° |
| Power Requirements | 100-240 VAC |
| Lens | F 1.7 - 1.9 (f = 25.6 - 35.7 mm) |
| Ceiling Mountable | Yes |
| Fan Noise | Normal Mode: 30 dB, Eco Mode: 28 dB |
| Rear Screen Projection | Yes |
| Life | Normal Mode: 4000 Hours |
| Lamp Bulb | 2x UHM |
| Watts | 310 W |
| Picture in Picture | Yes |
