Details
With the incorporation of the 420 W dual lamp and lamp drive system, the PT-DW830 series is able to deliver a high brightness of 8,500 lumens in an incredibly compact body. The Panasonic proprietary Dynamic RGB Booster, which has been enhanced, provides images with brilliant color and brightness, optimizing lamp intensity of individual red, green and blue colors according to each scene. Detail Clarity processor improves the clarity, detail and depth of images and the system daylight view function also helps maintain picture quality, even in a bright room. The series is 3D-compatible and supports various 3D formats including frame packing, side by side, top and bottom, line by line and simultaneous.
Features
• 8500 ANSI lumens is enough power to overwhelm most ambient light
• 10,000:1 contrast achieved by the Dynamic Iris delivers WXGA (1280 x 800) imagery that leaps off the screen
• Detail Clarity Processor 3 restores any subtle details that may have been lost during the compression process
• The projector ensures minimal image degradation and a quick response that eliminates afterimages
• Other features include a built-in clock to schedule projector functions, PIP, and DICOM simulation mode
• Panasonic's Dual Lamp System eliminates interruptions due to lamp failure (in Dual Lamp operation mode)
• The Dynamic Iris achieves a high contrast ratio of 10,000:1
• Vivid Color Control
• Panasonic's RGB Booster achieves high image quality with levels of color reproduction and brightness that make each color stand out
• Optimal color reproduction can be achieved by selecting this mode, compliant with ITU-R Recommendation BT.709, when images from an HDTV source are projected
• Waveform Monitor Function
• Exclusive to Panasonic, this image-processing circuit analyzes the video signal frequency range for each scene by extracting data on the distribution of high, mid, and low-frequency components, and brings out fine details accordingly
• A lens-centered design, a wide range of optional lenses, powered H/V-lens shift, and flexible vertical 360-degree installation enable smooth flexibility for use in various locations
• 3D color management system
• Full 10-bit image processing
• Progressive cinema scan (3:2 pulldown)
• Dynamic sharpness control
• Multi Projector Monitoring & Control Software
• cooling fan continues to operate even when the main power switch is turned off after projection is finished
• Multi-Screen Support System Seamlessly Connects Multiple Screens
• scheduling function enables timed operation via a built-in clock to program the projectors to turn on or off at specific hours during the day
• Anti-theft features with chain opening
• Control device setup function
• ID assignment for up to 64 units
• Built-in test pattern
Additional Information
| Aspect Ratio | 16:10 |
|---|---|
| Brightness (ANSI Lumens) | 8500 Lumens |
| Contrast Ratio | 10000:1 |
| Power Consumption | Normal Mode: 1030 W, Standby Mode: 3 W, Standby Mode (Network off): 0.3 W |
| Operating Temperature | 32 to 113°F (0 to 45°C) |
| Resolution | 1280 x 800 (WXGA) |
| Operating Humidity | 10 - 80% |
| Keystone Correction | Vertical: ± 40° |
| Power Requirements | 120-240 VAC, 50/60 Hz |
| Uniformity | 90% |
| Ceiling Mountable | Yes |
| Fan Noise | Normal Mode: 40 dB, Eco Mode: 37 dB |
| Built-in Speaker | Yes |
| Color Range | R, G, B, W |
| Rear Screen Projection | Yes |
| Security | Cable lock slot |
| Lamp Bulb | 2x UHM |
| Format | NTSC 4.43, Pal 60, M, N, SECAM |
| Display System | Chip 0.65 DLP |
| Picture in Picture | Yes |
| Scan | Horizontal: 15 - 100 kHz, Vertical: 24 - 120 Hz |
