Details
- offers Active Stereo 3D and provides video over a single Cat 5 cable (HDBaseTTM)
- supporting point-to-point transmission of video signals
- up to WUXGA (1,920 x 1,200) at 60 Hz - takes away the need for multiple cables and connectors, leading to more simplicity and lower costs
- geared with three-chip DLP technology, the high-brightness
- operating on a voltage of 110V - 240V
- rugged projector that reduces noise and power consumption
- features a DICOM simulated mode
Features Brightness of 14,500 Lumens, WUXGA (1920 x 1200) Native Resolution, Uses Interchangeable Lenses, HDMI, HDBT, 5-BNC, VGA, HD-SDI, DVI In, 3G-SDI Input and Output, BarcoLink Compatible, Ethernet and RS-232 Controllable, IR Remote Included. Bring versatility into your venue with the Barco RLM-W14 14 500-Lumen WUXGA 3-Chip DLP Projector. By using separately sold interchangeable lenses it offers a variety of throw ratios image sizes and zoom ranges. Its HDMI HDBT 5-BNC VGA HD-SDI 3G-SDI and DVI inputs allow you to show images from a number of different sources. The projector is also BarcoLink compatible enabling you to transmit native WUXGA signals at 60 Hz to other projectors via a single BNC cable for simplified signal distribution. A 3G-SDI output is also available for daisy chaining multiple projectors. It can be controlled by Ethernet RS-232 or the included IR remote.
Product Highlights
- Brightness of 14,500 Lumens
- WUXGA (1920 x 1200) Native Resolution
- Uses Interchangeable Lenses
- HDMI, HDBT, 5-BNC, VGA, HD-SDI, DVI In
Additional Information
| Aspect Ratio | Native: 16:10, Supported: 5:4, Supported: 4:3, Supported: 16:9, Supported: 1.88:1, Supported: 2.35:1, Supported: 1.33:1 |
|---|---|
| Brightness (ANSI Lumens) | 14500 Lumens |
| Contrast Ratio | 2400:1 |
| Resolution (Native / Max) | WUXGA (1920 x 1200) |
| Power Consumption | Maximum: 1230 W, Standby Mode (Normal): <2 W |
| Lamp Life | 2000 hrs |
| Lens Shift | Horizontal: ± 30%, Vertical: 70 - 130% |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Operating Humidity | 0 - 80% |
| Brightness Uniformity | 90% |
| Power Requirements | 90-240 VAC, 50/60 Hz |
| Life | Normal Mode: 2000 Hours, Normal Mode: 2000 Hours |
| Lamp Bulb | 2x NSH |
