Details
With the incorporation of the 420 W dual-lamp and lamp drive system, the PT-DW830 series is able to deliver a high brightness of 8,500 lumens in an incredibly compact body. The Panasonic proprietary dynamic RGB booster, which has been enhanced, provides images with brilliant color and brightness, optimizing lamp intensity of individual red, green and blue colors according to each scene. The PT-DW830 series offers more than just high picture quality, ease of maintenance, and system reliability. It is Digital Link compatible which guarantees users a simplified AV infrastructure with high definition video, audio, and control signals all carried over a single CAT5e or higher specification Ethernet cable for up to 100 meters.
Features
- Brightness of 8500 ANSI Lumens
- Resolution: 1280 x 800 (WXGA)
- Dual Lamp Design
- 10,000:1 Contrast Ratio
Additional Information
| Aspect Ratio | 16:10 |
|---|---|
| Brightness (ANSI Lumens) | Normal Mode: 8500 Lumens, Eco Mode: 6800 Lumens, Normal Mode: 4250 Lumens, Eco Mode: 3400 Lumens |
| Contrast Ratio | 10000:1 |
| Resolution (Native / Max) | 1280 x 800 (WXGA) |
| Throw Ratio | 1.8 - 2.5:1 |
| Operating Temperature | 32 to 113°F (0 to 45°C) |
| Remote Control | Yes |
| Operating Humidity | 10 - 80% |
| Brightness Uniformity | 90% |
| Keystone Correction | Yes, Vertical: ± 40° |
| Power Requirements | 120-240 VAC, 50/60 Hz |
| Lens | F 1.7 - 1.9 (f = 25.6 - 35.7 mm) |
| Fan Noise | Normal Mode: 40 dB, Eco Mode: 37 dB |
| Altitude | 0 - 8858' (0 - 2699 m) |
| Rear Screen Projection | Yes |
| Projection Size | 50 - 600" / 1270.00 - 15240.00 mm |
| Life | Normal Mode: 3000 Hours, Eco Mode: 4000 Hours |
| Lamp Bulb | 2x UHM |
| Watts | 420 W |
| Picture in Picture | Yes |
