Details
Features
A full 4,500 lumens of brightness and contrast of 2,000:1
The 300-watt AC lamp unit features an efficient light focusing reflector. Using only a single lamp unit, the PT-DX500U achieves 4,500 lumens of brightness. It boasts a high contrast ratio of 2,000:1.
RGB booster significantly improves color reproduction
The RGB booster achieves high image quality with levels of color reproduction and brightness that make each color stand out. It combines Panasonic's proprietary vivid color control technology with a lamp modulation drive system for a 1-chip DLP projector that produces bright and vivid colors.
Detail Clarity Processor 3 brings depth and clarity to details
The frequency of the video signal is analyzed for each scene, and distribution data is extracted for the ultra high, high, medium and low-range frequencies. This unique Panasonic image correction circuit optimally enhances each area of the screen. High-precision detection is applied from 2-dimensional horizontal/vertical data to produce more natural, lifelike images with high definition.
Daylight view premium for better color perception
This function corrects the image quality to project sharp, clear images even in brightly lit rooms. A luminance sensor measures the ambient brightness, and a realtime adjustment function optimizes sharpness and brightness according to the surroundings. This adjustment function also works together with the Detail Clarity Processor 3 to enhance the realism and vividness of projected images. This makes images easier to view and offers high contrast.
Easy lamp replacement
For easier maintenance, you can replace the lamp from the rear. The lamp is easily replaced even after the projector is installed on the ceiling.
Flexible angle setting
The unit can be rotated 360° vertically. This means you can install it at any up-and-down angle you wish to accommodate different installation conditions.
Lens-centered design
A lens-centered, symmetrical design provides ease of installation, eliminating the need for any special considerations when planning the installation site.
Eco management functions
A number of functions are provided to reduce power consumption. It adjusts the brightness according to the ambient light conditions and reduce the lamp power when there is no signal input or the projector is in the AV mute mode.
Additional Information
| Aspect Ratio | Native: 4:3 |
|---|---|
| Brightness (ANSI Lumens) | 4500 Lumens |
| Contrast Ratio | 2000:1 |
| Resolution (Native / Max) | 1024 x 768 (XGA) |
| Power Consumption | Normal Mode: 415 W, Standby Mode: 15 W, Eco Mode: .3 W |
| Projection Screen Size (Diagonal) | 40 - 300" / 1016.00 - 7620.00 mm |
| Throw Ratio | 1.51 - 3.05:1 |
| Operating Temperature | 32 to 113°F (0 to 45°C) |
| Remote Control | Yes |
| Operating Humidity | 0 - 45% |
| Keystone Correction | Vertical: ± 40° |
| Power Requirements | 100-240 VAC, 50/60 Hz |
| Lens | F 2.0 - 3.4 (f = 21.5 - 43.0 mm) |
| Ceiling Mountable | Yes |
| Pixels | 786,432 |
| Fan Noise | Normal Mode: 29 dB |
| Zoom | 2x |
| Rear Screen Projection | Yes |
| Life | Normal Mode: 2000 Hours, Bright Mode: 3000 Hours |
| Lamp Bulb | 1x UHM |
| Format | NTSC, PAL, SECAM |
| Watts | 300 W |
