Details
The HDX-W20 FLEX is the most compact rugged projector that offers 20,000 lumens light output currently available. One of its most striking features is that it is standard equipped with the light-on-demand option for flexible light output.
Choose your brightness
Thanks to the light-on-demand option, you can fully tune the light output of the projector to your event: it can be programmed to a light output of 10,000 to 20,000 lumens in 2,000 incremental steps. Rental companies now have the flexibility to offer their customers the light output they want.
Flexible scaling
Building on Barco's renowned ImagePRO series with Athena™ scaler, the HDX is equipped with on-board image processing for unlimited and flexible scaling. This boosts creativity and minimizes the time it takes to get sources on screen.
Quick preview and wireless control
The HDX-W20 FLEX's built-in color LCD screen provides you with all the information you need on your projector's status and allows you to preview your connected sources. Whether from one central PC or via the Android projector control app for smartphone or tablet computer, you remain connected to the HDX at all times.
3G/BarcoLink compatibility
The HDX-W20 FLEX has a native 3G HDSDI/SDI input, which makes it compatible with progressive HD sources over a single BNC cable. This also means that the HDX allows for digital inputs that don't come through fragile DVI fiber cables. What's more, the projectors also feature BarcoLink, enabling progressive WUXGA 50/59.94/60 Hz signal distribution over a single BNC coax cable.
Compact projector with just five building blocks
As the HDX-W20 FLEX is the smallest and lightest 20K lumens projector on the market, it can easily be boxed and shipped, and it fits into standard flight cases. It features just five building blocks that can be removed and replaced quickly.
Additional Information
Aspect Ratio | Native: 16:10, Supported: 4:3, Supported: 5:4 |
---|---|
Brightness (ANSI Lumens) | 20000 Lumens |
Contrast Ratio | 1850:1 |
Display Type | WUXGA (1920 x 1200) QXGA (2048 x 1536) |
Resolution (Native / Max) | 1920 x 1200 (WUXGA) |
Dimensions (WxHxD) | 18.7in. x 15.0in. x 28.5in.(47.5cm x 38.1cm x 72.39cm) |
Weight | 110.0 lbs. (49.9 kg) |
Inputs | 1 x DVI-I 5 x BNC 1 x RGB D-Sub 15pin |
Control | 1 x RS-232 |
Power Supply | 200 ~ 240 V / 50 ~ 60 Hz |
Power Consumption | Normal Mode: 2850 W, Standby Mode: <8 W |
Audible Noise | 58 dB |
Lamp Type | 2.5kW Xenon |
Projection Mode | Front, Rear, Ceiling |
Lamp Life | 1000 hrs |
Lens Shift | Vertical: - 120%, Horizontal: ± 40% |
Operating Temperature | 32 to 104°F (0 to 40°C) |
Storage Humidity | 5 - 95% |
Operating Humidity | 5 - 80% |
Brightness Uniformity | 90% |
Dot Clock | 200 MHz |
Power Requirements | 200-240 VAC, 50/60 Hz |
Storage Temperature | 5 to 140°F (-15 to 60°C) |
Lamp Bulb | 1x Xenon |
