Aspect Ratio |
16:9 (native), 4:3, LBX and auto compatible |
Audio |
2x 5 Watt Speakers, Loop through |
Brightness |
5,000 ANSI lumens |
Color Wheel |
6 segment RYGCWB |
Connections |
1x HDMI (2.0 w/ HDCP 2.2, MHL 2.1), 1x HDMI (1.4a), 1x VGA, 1x audio (3.5mm), 1 x USB (power / 1.5A), 1x USB (service), 1x audio out (3.5mm), 1x S/PDIF (optical) |
Contrast Ratio |
10,000:1 |
Display Technology |
Texas Instruments 0.66” 4K UHD DMD |
Displayable Colors |
1.07 billion |
Image Size |
26.45”-302.2” |
Light Source Type |
330W |
Light Source Life |
Up to 5,000/4,000/3,000 (Dynamic/ECO/Bright) |
Lens Shift |
Vertical: +15% |
Maximum Resolution |
4K (4096 x 2160) |
Native Resolution |
4K UHD (3840 x 2160) |
Noise Level |
32dB (Eco) |
Offset |
100% |
Operating Temperature |
41–104°F (5–40°C), 85% max humidity |
Power Consumption |
419W typical (Bright), 461W max (Bright), 331W typical (Eco), 364W max (Eco) |
Power Supply |
AC input 100–240V, 50–60Hz, auto-switching |
Projection Distance |
4.3’ – 30.5’ |
Projection Lens |
F/2.5-3.26; f=20.91-32.62mm |
Remote Control |
Full size remote with laser |
Throw Ratio |
1.39-2.22 |
Uniformity |
75% |
Zoom Type |
1.6x optical (manual) |
|
