| Aspect Ratio |
16:9 (Native), 4:3, Auto |
| Brightness (ANSI Lumens) |
4600 ANSI Lumens |
| Contrast Ratio |
10,000:1 (full on/full off) |
| Display Type |
Single 0.65” 1080p chip, DLP® Technology from Texas Instruments™ |
| Resolution (Native / Max) |
1080p 1920 x 1080 |
| Video Compatibility |
PAL (B, D, G, H, I, M, N, 4.43MHz), NTSC (M, J, 3.58MHz, 4.443MHz), SECAM (B, D, G, K, K1, L, 4.25MHz, 4.4MHz, 480i/p, 576i/p, 7 |
| Projection Lens |
F=2.5~3.26, f=20.91~32.63 mm; manual focus |
| Power Supply |
AC input 100–240V, 50–60 Hz, auto-switching |
| Power Consumption |
421W Max (Bright), 329W Max (ECO), <0.5W (Standby) |
| Projection Screen Size (Diagonal) |
26.2"~301.1" (0.66–7.64 m), Diagonal 16:9 |
| Throw Ratio |
1.41:1~2.24:1 |
| Vertical Keystone Correction |
±30° Vertical; ±30° Horizontal |
| Lamp Life |
3500/3000 (hrs) |
| Lens Shift |
Vertical: +17%(constraints apply see user manual for details) |
| Projection Distance |
51.18"–370" (1.3–9.4 m) |
| Operating Temperature |
41~113°F (5~45°C) |
| Operating Humidity |
85% max humidity |
