Aspect Ratio |
4:3 |
Brightness (ANSI Lumens) |
6,000 Lumens |
Contrast Ratio |
2,000:1 (full on/full off) |
Resolution (Native / Max) |
WUXGA (1920 x 1200) |
Projection Lens |
5 x lens options "no lens supplied as standard" |
Number of Colors |
1.07 Billion |
Dimensions (WxHxD) |
W 16.9" x D 13.4" x H 7.1" |
Inputs |
1x HDMI (1.4a 3D support), 1x DVI-D, 1x DisplayPort, 1x 5BNC, 2 x VGA-In (RGB/YPbPr), 1x Component Video (3 x RCA), 1x S-Video, |
Outputs |
VGA out, +12V trigger, 3D VESA port, audio out (3.5mm), USB-A power |
Power Supply |
AC input 100-240V, 50-60 Hz, auto-switching |
Power Consumption |
480W Max (Bright mode), 330W (STD mode), <0.5W (standby) |
Projection Screen Size (Diagonal) |
Dependent upon lens |
Throw Ratio |
0.8 ~ 5.18:1 "Lens dependent" |
Audio |
2x 3 Watt Speakers |
Lens Shift |
-20~100% V, ±10% H |
Projection Distance |
Dependent upon lens |
Operating Temperature |
Sea Level to 10,000 feet (@73°F); must manually switch to high-altitude mode at 5,000 feet & above |
Remote Control |
Infra-red remote control, Multiple IR code sets for controlling multiple units, Wired connection sup |
Native Resolution |
XGA (1024 x 768) |
Keystone Correction |
±30° Vertical |
Uniformity |
85% |
Zoom |
Dependent upon lens |
Security |
Security bar, Kensington lock, password protection, keypad lock |
